PIM Shield Torque Wrenches,
Proper installation torque is required for any bolted connection to achieve low PIM performance. ConcealFab has determined the optimum torque for each of its PIM Shield cable support systems and offers convenient, fixed torque wrenches for each torque requirement.
Technical Data
| Part Number | Description | Technical Datasheet | Installation Guide | Mechanical Outline Drawing |
|---|---|---|---|---|
| 901039 | Torque Wrench, Fixed, 9/16-IN Head, 4 FT-LB (5.4 Nm) | Download | ||
| 900053 | Torque Wrench, Fixed, 9/16-IN Head, 10 FT-LB (13.6 Nm) | Download | ||
| 900412 | Torque Wrench, Fixed, 17mm Head, 15 FT-LB (20.3 Nm) | Download | ||
| 900413 | Torque Wrench, Fixed, 3/4-IN Head, 20 FT-LB (27.1 Nm) | Download | ||
| 901522 | Torque Wrench, Fixed, 22mm Head, 5.9 FT-LB (8.0 Nm) | Download |
